The elegantly designed amps convey their qualities as soon as they are touched: No rattling sheet metal, heat sinks and end panels made of brushed aluminum and a flush MUSWAY logo on top. The amplifiers have everything on board that a modern sound system needs: EPS, auto turn-on, high and low level inputs and much more.
Start-Stop ready, Auto Turn-On
EPS (Error Protection System)
Interference Free Technology, EMC proved
PURE IN>OUT Function
High and Low Level Inputs
Brushed aluminum heat sink and end panels
Compact Bass Level Remote Controller
EPS technology which prevents when connected to an OEM factory radio that nofunctions are impaired or error messages are written into the vehicle memory.
4 -fold laminated board effectively suppresses EMC interference due to the favorable topology.
Every channel pair can be bridged. Bridging amplifier channels enables more flexibility to handle the power.
Pure amplification function allows you to fine tune the sound via DSP.
Power output(RMS) @ 14.4 VDC, 1% THD:
1x250/400/650@ 4 Ω/2 Ω/1 Ω
Subsonic-Filter 10 - 40 Hz
Lowpass Filter 40 - 150 Hz
Bass Boost 0 - 18 dB, Phase 0 - 180°
Filter Bypass Function (Pure Amplification)
Quick Connect Speaker Output
Dimensions: 150 x 45 x 200 mm
